DB01 is a Bluetooth beacon data system with temperature & humidity sensor, It can record data locally or transmit data to the host or cellphone through Bluetooth broadcast, and then upload the data to the server by the host or cellphone, It plays a significant role in logistics and cold chain, helping customers to achieve transparent management, educe costs, ensure safety, and improve efficiency.
chips
BLE 5.0
Range
Temperature measuring range: -20 °C to +60 °C; Humitidy measuring range: 0%RH to100%RH
Accuracy
Typ(±0.5°C ±2%)
sensor
Built-in light sensor,Built-in acceleration sensor,
Alarm
Support temperature and humidity alarm, light alarm, vibration alarm, tilt alarm, low battery alarm
Data
Real-time data (Date,time,temperature,humidity,battery,Mac address)converting, storing and uploading. 4M flash. It can save 100.000 pieces data
USB
Get history data by connect USB to PC directly.
Bluetooth Gateway Device
TK419-3 ,TK419, TK418，GPT46
Physical specification
| Dimensions | 101(L)x42(W)x11.5(H)mm |
| Display | LCD (120*120px) |
| Net Weight | 42g |
Power
| Battery type | Button Battery |
| Battery Capacity | 600mAh |
| Voltage | 3.0VDC |
Memory
| Memory capacity | 4M flash. |
| Working mode | cycle overwrite storage, It can save 100.000 pieces data |
Interface
| LED indication | Alarm&Mark (Red) |
| KEY | turn on/off Bluetooth broadcas,mark data,Menu page flip etc |
Operating environment
| Working temperature & humidity | -20℃~60℃;20%~90% RH |
| Storage temperature & humidity | +5°C ~ +35°C ,45%RH~85%RH |
| IP rate | IP65 |
Protocol
| Protocol | custom broadcast protocol, Eddystone，iBeacon; |
